China Q69 Roller conveyor machinery shot blasting cleaning equipment

  • 1 - 1 Sets
    $50,000.00
  • >=2 Sets
    $48,000.00
Feature:
Rust / Corrosion Inhibitor
Industry Used:
Steel structure, steel plate, etc
Model Number:
Q69
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Samples:
$48,000.00 /Set | 1 Set (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Machine Type:
Abrator
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Puhua
Weight (KG):
10000 KG
Fuel:
Electric
Certification:
ce, ISO
Use:
burnishing
Cleaning Process:
Steel shot, steel grit
Cleaning Type:
Clean-In-Place (CIP)
Material:
Metal / Coil
Power:
Customized
Dimension(L*W*H):
Customized
Warranty:
1 YEAR
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Key Selling Points:
Easy to operate
Local Service Location:
philippines, RUSSIA
Showroom Location:
philippines, RUSSIA
Applicable Industries:
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Construction works , Energy & Mining, Advertising Company
Name:
Roller conveyor shot blasting equipment
Application:
Steel Plates, steel structure
Color:
Customers Requirement
Shot blast machine type:
Roller Conveyor Shot Blasting
Blast chamber:
Rolled Mn13 Steel Guard Plate
Function:
Metal Surface Cleaning
Supply Ability
Supply Ability:
30 Set/Sets per Month machinery equipment
Packaging & Delivery
Packaging Details
In bulk, stretch film
Port
Qingdao Port
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 35 To be negotiated
Product Description

Machine application.

1. This machinery equipment, Q69 shot blasting machine,  is mainly used for the surface cleaning of large steel parts, such as steel structures, steel plates, steel pipes, H beams, etc.

2. It can eliminate the internal stress, descale and remove rust, welded slages, oxide scales or other contaminants from Beams, Structural Steels, Profile Steels, Billets etc. components, make the cleaned components to obtain a clean surface with a certain roughness and improve the adhesion of painting, coating or other surface treatments.

3. It can be combined with spray paint and drying to form a production line.

4. Blasting chamber guard plate material is optional, ZGMn13, SPMn13, etc, wear-resistant parts.

4. Q69 shot blasting machine is composed of blasting chamber, abrasive recycling system, roller conveyor system. control cabinet, etc.

Parameter
Q698
Q6912
Q6915
Q6920
Q6925
Q6930
Q6940
Effective cleaning width (mm)
800
1200
1500
2000
2500
3000
4000
Room feed-in size(mm)
1000*400
1400*400
1700*400
2200*400
2700*800
3200*800
4200*400
Length of cleaning workpiece (mm)
1200-12000
1200-12000
1200-12000
1200-12000
3000-12000
2400-12000
4500-18000
Speed of conveyor (m/min)
0.5-4
0.5-4
0.5-4
0.5-4
0.5-4
0.5-4
0.5-4
Thickness of cleaning
steel sheet (mm)
3-60
3-60
3-60
3-60
3-60
3-110
4.5-100
Section steel specification(mm)
800*300
1000*300
1500*300
2000*300
2500*700
3000*700
4000*300
Blasting capacity(kg/min)
4*180
4*250
4*250
6*250
6*250
6*360
8*360
First loading quantity(kg)
4000
4000
4000
4500
4500
8000
11000
Detailed Images
Packing & Delivery
Our Service


1. Installation and commissioning issue:
We will send 1-2 technicians to assist with machine installation and commissioning, customer pays for their tickets, hotel and diet, etc. Customer need arrange 3-4 skilled worker and prepare insallation machinery and tools.

2. Warranty time:
12 months from date of commissioning completion, but no more than 18 months from date of delivery.

3. Supply full English documents:
including foundation drawings, manual book, electric wiring diagram, electric manual book and maintenance book,etc.

Our Company

Warmly welcome you to visit us in Qingdao China.
