Q37 Hook Type Shoot Blasting Equipment Machinery

  • 1 - 1 Sets
    $20,000.00
  • >=2 Sets
    $19,000.00
Model Number:
Q37
Feature:
Non-Ionic NON-TOXIC Rust / Corrosion Inhibitor
Industry Used:
Electronic Industry OTHER
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Machine Type:
Abrator
Condition:
New
Place of Origin:
Shandong,China(Mainland)
Brand Name:
Puhua
Video outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
Hot Product 2019
Warranty of core components:
1 YEAR
Core Components:
PLC, Gearbox, MOTOR
Weight (KG):
7000 KG
Fuel:
Electric
Certification:
CSA, ce, ROHS, UL, GS, UR, ETL, CB, ISO
Use:
burnishing
Cleaning Process:
Steel shot
Cleaning Type:
manual
Material:
Metal / Coil
Power(W):
Customized
Dimension(L*W*H):
Customized
Warranty:
1 YEAR
After-sales Service Provided:
Field installation, commissioning and training
After Warranty Service:
Video technical support, Online support
Key Selling Points:
long service life
Local Service Location:
INDIA, south africa
Showroom Location:
INDIA, south africa
Applicable Industries:
Building Material Shops, Manufacturing Plant, Machinery Repair Shops, farms, Retail, Construction works
Product name:
Steel Shot Blasting Machine
Application:
steel workpiees shot blasting
Type:
Shot Blasting Machine Equipment
Function:
Metal Surface Cleaning
Color:
Custermized
Machine:
Steel Surface Treatment Machine
Name:
Q37 Hook Type Shoot Blasting Equipment Machinery
Product Certification certification
CE Certified.
Valid from 2017-12-21 until 2022-12-21
Supply Ability
Supply Ability:
300 Set/Sets per Year
Packaging & Delivery
Port
Qingdao
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated

Customizable Hook Shot Blasting Machine With Strong Shot Blasting Performance

Q37 Series Hook Type Shot Blasting machine is for surface cleaning or strengthening treatment of small castings, forging parts in industry of foundry, building, chemical, motor, machine tool etc. It is special for surface cleaning and blasting strengthening on various types, small production castings, forging parts and steel construction parts for clearing little viscous sand, sand core and oxide skin. It is also suitable for surface cleaning and strengthening on heat treatment parts, especially for cleaning slightness, thin wallparts which is not suitable for impact. hook shot blasting machine


Main Features

This series is hook type shot blasting machine, is mainly used for surface cleaning of casting, structure, non-ferrous and other parts. This series shot blasting machine have many types, such as single hook type, double hook type, lifting type, non-lifting type. It has advantage of non-pit, compact structure, high productivity, etc.

1). The equipment is mainly applied in the processing of medium and small size workpieces in large scale. It has the advantage of high efficiency, compact structure.
2). Workpieces can be transported continuously. The working procedure is that, setting the speed, hanging workpieces over the hooks, and removing them after shot cleaning.
3). Each single hook can hang weight from 10 kgs to 5000 kgs with high productivity and stable running.
4). It makes a best effect on complicated workpieces both the surface and inner part, such as cylinder cap of engine and motor casing.
5). It is an ideal choice for auto, tractor, diesel engine, motor and valve industry. shot blasting machine hook type

Item
Unit
Q376
Q376B
Q378C
Q3710
Q3720
Q3730
Q3750
Maximum weight of cleaning
kg
500
600
800
1000
2000
3000
5000
Abrasive flow rate
kg/min
2*200
2*200
2*250
2*250
3*250
3*250
4*250
Ventilation on capacity
m³/h
5000
5000
5000
5000
9000
11000
14000
Lifting amount of elevating conveyor
t/h
24
24
30
30
45
45
60
Separating amount of separator
t/h
24
24
30
30
45
45
60
Max overall dimensions of suspender
mm
600*
1200
700*
1200
1000*
1600
1200*
1800
1400*
2200
1600*
2300
1800*
2500
1. Installation and commissioning issue: We will send 1-2 technicians to assist with machine installation and commissioning, customer pays for their tickets, hotel and diet, etc Customer need arrange 3-4 skilled worker and prepare insallation machinery and tools. 2. Warranty time: 12 months from date of commissioning completion, but no more than 18 months from date of delivery. 3. Supply full English documents: including foundation drawings, manual book, electric wiring diagram, electric manual book and maintenance book,etc.
shot blasting machine hook type
    Why      us?

1.Owned factory, better quality control

2.Rich experienced in manufacturing and exporting

3.Competitve price and reliable oversea after-sale network
